Reverse Engineering

At Vigrotek, we perform versatile Reverse Engineering which include Plastics, Sheet metal and Castings and Forgings and machined parts. Customers who do not have the records of their running products and would like to have the product re produced or want to have some improvements do consider us as their extended arm. We perform reverse-engineering process that holistically captures product design information such as dimensions, features, material properties.

We combine our Design for Manufacturability knowledge and Design for Assembly knowledge to produce a desirable output to the customers. Based on the captured information, we help our clients to identify the design intent of a product and deliver manufacturing drawings.

Our brief process include

Feature analysis: detailed study to determine the technical features and functional aspects of the equipment

Scanning and Digitalization: a systematic process that employs advanced 3D scanning to measure complex geometry of components

Material & Dimensional Inspection : study of the product material properties through Material test labs

CAD model building: creation of parametric 3D CAD models, BOM and conformance check to ensure the manufacturability of the part

Manufacturing drawing: creation of manufacturing drawings with DFM and DFA considerations
